Details
Performance | |
rated load | 5000kg |
overall weight | 15500kg |
rated bucket capacity | 3 |
maximum tractive force | 150KN |
maximum breakout force | ≥160KN |
maximum grade ability | 30° |
maximum dump height | 3200mm |
maximum dump reach | 1264mm |
overall dimension (L×W×H) | 7900×3024×3460mm |
minimum turning radius | 6201mm |
Engine | |
model | Weichai Steyr WD10G220E21 |
type | China Phase II,Inline 6-cylinder,four stroke |
No. of cylinder-bore/stroke | 6-126×130mm |
rated power | 162kw--2400r/min |
maximum torque | 920N.m |
min fuel-consume ratio | ≤215g/kw.h |
Transmission system | |
torque converter | single-stage four-element double-turbine hydraulic torque converter |
gearbox mode | Planetary power shift |
gear shift | 2 forward shift 1reverse shift |
maximum speed | 38km/h |
Drive axles | |
main reducing spiral | bevel gear grade 1reduction |
decelerating mode | planetary reduction,grade 1 |
wheel base (mm) | 2920mm |
wheel tread | 1500mm |
minimum ground clearance | 480mm |
Hydraulic system | |
system working pressure | 18MPa |
boom lifting time | 5.95±0.2s |
total time | 10.95±0.5s |
fuel tank capacity | 265L |
function of leveling automatically | yes |
Brake system | |
service brake | air over hydraulic disc brake on 4 wheels |
parking brake | manual parking brake |
Tyre | |
type specification | 23.5-25 |
front tyre pressure | 0.4Mpa |
rear tyre pressure | 0.35Mpa |
Yantai Xinyu Heavy Industry Technology Co., Ltd. is a professional manufacturer of construction machinery and a professional enterprise that produces small tire loaders for engineering purposes. This place boasts charming scenery and prosperous economy, serving as the junction of Yantai, Qingdao, and Weifang. The Weiwu Expressway, Dalailong Railway, National Highway 206, and Laizhou Port with 10000 ton berths run through the east, west, north, and south, with convenient transportation and superior geographical location.
Our company has passed the certification of the National Bureau of Technical Quality Supervision and obtained the Special Equipment Manufacturing License, and is listed as a national special equipment production enterprise. The company has an experienced and innovative workforce, consisting of 40 employees, 15 professional and technical personnel, and 4 engineers. It also has comprehensive inspection and monitoring methods and a quality assurance system. Since its establishment, our company has always adhered to the principle of "quality first, sincerity"
The business philosophy of "believing in the world" has won the bid with its strong mechanical design, production and manufacturing capabilities, first-class product quality, and good after-sales service.The recognition and praise of the vast number of users.
