Details
Project | Parameter |
Bucket capacity | 0.6m |
Rated load capacity | 1.2t |
Maximum shovel force | 40 KN |
Maximum traction force | 38KN |
Minimum unloading distance | 785mm |
Maximum unloading height | 1020mm |
Climbing ability (full load) | ≥ 16 ° |
Minimum turning radius | 3445mm on the outer side and 1900mm on the inner side |
Maximum steering angle (left/right) | 38 ° |
Departure angle | 16 ° |
Driving speed (bi-directional) | 0-7km/h |
Motor model/power | HM2-2-225S-4/37kw |
braking system | Integrating work brake and parking brake, using spring brake and hydraulic release brake |
External dimensions (length x width x height) | 4750x1100x1840mm |
Overall weight | 5.1t |
1. Adopt the latest generation of 90 series variable hydraulic pump and hydraulic motor of Saodanfoss in the United States, which is different from other factories
Home old pv22, mv 23 series. The United States SAO hydraulic system is an international famous brand, the failure rate is low and the match is perfect, and the Huali motor HM2-225S-4 to achieve the best match, that is, to give full play to the maximum efficiency of the motor, effectively ensure the service life of the vehicle and the axle, reduce the maintenance cost, improve equipment attendance and mining efficiency.
2. Carefully researched and developed, the original latest generation of cable servo system, to ensure that the cable no matter what the vehicle is in
The output state can keep pace with it, better protect the cable from accidental damage, and effectively extend the service life of the cable.
3. The vehicle frame and plate use Q345B low alloy steel as the main material of the frame, and the lower yield limit of the material is in
About 345Mpa, can withstand a variety of loads from inside and outside the car. Not only the strength is guaranteed, but also through normalizing, time
Efficiency, sandblasting, anti-corrosion and other seven processes welded forming, so meet the frame and working device structure, power,
Sports and other requirements.
4. Drive axle selection of heavy PC15 bridge, compared with other manufacturers of light bridge, durable, strong impact resistance
High degree, reduce the failure rate. The drive axle is normally closed wet drive axle, through spring braking, hydraulic release,
Reliability and safety are improved, suitable for complex underground road conditions and shovel loading conditions.
5. The copper sleeve of the whole machine is made of high-force brass and radially embedded cylindrical graphite filler arranged in order as friction material.
The embedded solid lubrication is easy to form a lubricating film, which plays a great role in its friction and wear performance, and has high precision and bearing
Strong load capacity, good wear resistance characteristics.
6. The pin is made of 40Cr alloy steel, which needs to be roughed, tempered, refined, quenched, and refined
The stability of the pin during the working period is verified.
7. The hydraulic tank adopts pickling and high pressure treatment technology, which is different from manual cleaning by other manufacturers, so as to ensure
The cleanliness of the hydraulic system is proved, so that the pump and motor can be used longer.
8. The swing design of the rear axle with intermediate slewing bearing makes the structure more reasonable, and the operation comfort and safety are better.
9. The cylinder is added with the whole follow-up protection device to protect the cylinder piston rod from falling rock impact damage, effective protection
Cylinder for extended service life.
10. The hydraulic tubing and joints are all imported famous brands, such as Horse brand, Goodyear and other manufacturers
Life is greatly extended.
11. The blade is made of Baosteel special wear-resistant 500 plate, abrasion resistance and shear resistance, which is the service life of ordinary wear-resistant steel plate
1.5-2 times.
12. High-quality wiring harness: high temperature wire, wear-resistant, waterproof, low temperature resistance, high temperature resistance, not easy to burn, not easy
Aging; The wire harness periphery uses high-quality corrugated tee and imported Deutsch waterproof plug, which is superior to domestic counterparts.
13. The cable adopts the well-known domestic brand Shanghai Cable factory, and the quality is effectively guaranteed
· Yantai Xinyu Heavy Industry Technology Co., Ltd. is a professional manufacturer of construction machinery and a professional enterprise that produces small tire loaders for engineering purposes. This place boasts charming scenery and prosperous economy, serving as the junction of Yantai, Qingdao, and Weifang. The Weiwu Expressway, Dalailong Railway, National Highway 206, and Laizhou Port with 10000 ton berths run through the east, west, north, and south, with convenient transportation and superior geographical location.
Our company has passed the certification of the National Bureau of Technical Quality Supervision and obtained the Special Equipment Manufacturing License, and is listed as a national special equipment production enterprise. The company has an experienced and innovative workforce, consisting of 40 employees, 15 professional and technical personnel, and 4 engineers. It also has comprehensive inspection and monitoring methods and a quality assurance system. Since its establishment, our company has always adhered to the principle of "quality first, sincerity"
The business philosophy of "believing in the world" has won the bid with its strong mechanical design, production and manufacturing capabilities, first-class product quality, and good after-sales service.The recognition and praise of the vast number of users.
FAQ :
1. What Certificate do you have?
· TDER workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate. Some of our products meets the EPA requirements.
TDER never recruit Underage labor.
2. Can you customize and design as the clients' requirement?
TDER will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.
3. How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the TDER
warranty policy for each model.
4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.
5. Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is 30 days.
